10 Cu. Ft. Refrigerator & Freezer (-40°C Operation) Combination, with Glass Door Refrigerator

Product Number: ABT-HC-RFC1040G



The Premier Dual Temp Combination units feature separate microprocessor temperature controller allowing for precise temperature control, verification and recovery. An interior fan driven, forced-draft air circulation system provides excellent temperature uniformity and recovery after door openings. REFRIGERATORS ONLY

All models are equipped with digital temperature displays for convenient monitoring. Critical samples and supplies are security backed with an extensive package of audible and visual alarms. The freezer units feature either an automatic or manual defrost operating system. For manual defrost freezers, periodic manual defrosting is required.

This model requires 4” of clearance around back and sides of the unit for proper ventilation. Improper installation will void the warranty and will lead to temperature maintenance issues, overheating and possible failure.

Environmentally friendly, natural hydrocarbon (HC) refrigerants (not containing hydrofluorocarbons) vastly reduce global-warming potential (GWP) while meeting new EPA/SNAP mandates and UL, ASHRAE compliance guidelines.

Request a Custom Quote

Get pricing and availability for this product

Product Inquiry
Gelu

Ask Gelu about the ABT-HC-RFC1040G

Here are common questions and answers about this product

Gelu is on every product pageJust ask a question, anytime
What's the temperature range for each compartment?

The freezer has an adjustable operating range of -37°C to -43°C, and the refrigerator has an adjustable range of 2°C to 8°C.

Temp Controller tab
What are the exterior dimensions and how much clearance is needed?

Exterior dimensions are 23 3/4″ W x 24″D x 65″H. The unit requires 4″ of clearance on the sides and back for adequate ventilation.

Specifications tab
How does defrost work on this combination unit?

The freezer is manual defrost, so periodic manual defrosting is required, while the refrigerator uses cycle defrost.

Specifications tab
What alarms and monitoring come with this unit?

It includes a microprocessor temperature controller with digital temperature display, audible and visual high and low temperature alarms, two probes (one in air and one in a sample bottle), and remote alarm contacts.

Temp Controller tab
What are the electrical requirements?

The unit runs on 115V, 60 Hz. The freezer draws 2.2 Amps with a 1/4 HP compressor, and the refrigerator draws 1.3 Amps with a 1/6 HP compressor.

Specifications tab
What refrigerants are used and what's the warranty?

The refrigerator uses HFC-free R600a and the freezer uses natural hydrocarbon R290 refrigerant. The warranty is two years parts and labor, plus an additional three year compressor parts only warranty.

Details tab
Answers come from this product's record and datasheet. Settings and procedures come from the owner's manual.

Product details for the ABT-HC-RFC1040G

The description, performance figures and controller details, straight from the datasheet.

Need the full datasheet? Use View / Print Product Information above.
Details
  • 5.2 cu. ft. capacity (Refrigerator) / 4 cu. ft. capacity (Freezer) One glass swing door (fridge), one solid swing door (freezer)
  • 3 adjustable shelves (freezer); 3 adjustable shelves (fridge)
  • Bottom footed shelf to allow air circulation
  • Back wall evaporator cover
  • Keyed door locks
  • Magnetic door gasket for positive seal
  • Recessed door handles
  • Stacking kit
  • Leveling legs
  • LED interior light
  • Probe access port (3/8″)
  • White cabinet and door
  • High density urethane foam cabinet and door insulation
  • HFC-free refrigerant (R600a) Refrigerator; Natural, Hydrocarbon refrigerant (R290) Freezer
  • Two year parts and labor warranty, plus an additional three year compressor parts only warranty

Accessories:

0504 BasketABT-SLD BSKT-FULL-0504



0504 Bottom BasketABT-BSKT-BASE-FIXED-0504

  • Exterior dimensions:23 3/4″ W x 24″D x 65″H
  • Note: This unit must have 4” clearance on sides and back for adequate ventilation
  • Manual defrost (freezer); Cycle defrost (refrigerator)
  • 115V, 60 Hz
  • 2.2 Amps, 1/4 HP (freezer); 1.3 Amps, 1/6 HP (refrigerator)
  • UL/C-UL listed
  • Shipping weight: 268 lbs.
  • Microprocessor temperature controller
  • Digital temperature display
  • Audible and visual high and low temperature alarms
  • 2 probes; 1 in air and 1 in sample bottle
  • Remote alarm contacts
  • Adjustable operating temperature range – Freezer: -37°C – -43°C; Refrigerator: 2°C to 8°C

Related Products

A pair of stacked, white laboratory refrigerators from American BioTech Supply. Each unit has a digital display, handle on the right, and green eco-friendly label on the bottom right of the door. The brand logo appears on the top left of both doors.
