10.5 Cu. Ft. Pharmacy Glass Door Compact Laboratory Refrigerator

Product Number: PH-ABT-HC-10PG

EnergyStarulGreen-Leaf-ABS


The Premier Pharmacy compact laboratory refrigerators feature a microprocessor temperature controller and display, allowing for precise temperature control, verification and recovery versus mechanical style thermostats. An interior fan driven, forced-draft air circulation system provides excellent temperature uniformity and recovery after door openings.

Freestanding models require 4” of clearance around back and sides of the unit for proper ventilation. Improper installation will void the warranty and will lead to temperature maintenance issues, overheating and possible failure.

For more information on Vaccine Storage: Vaccine Storage

The acceptable temperature ranges for vaccine storage are 36°F to 46°F (or 2°C and 8°C) in the refrigerator and -58°F and 5°F (or -50°C and -15°C) in freezers.

Environmentally friendly, natural hydrocarbon (HC) refrigerants (not containing hydrofluorocarbons) vastly reduce global-warming potential (GWP) while meeting new EPA/SNAP mandates and UL, ASHRAE compliance guidelines.

  • 10.5 Cu. Ft. Capacity
  • Six adjustable shelves with guard rail on back to prevent product from being pushed against back wall
  • Bottom footed shelf to allow air circulation
  • Back wall evaporator cover
  • Vaccine storage power cord warning label
  • Forced draft circulation
  • Keyed door lock
  • Magnetic door gasket for positive seal
  • Leveling legs
  • LED interior light
  • Probe access port (3/8″)
  • HFC-free refrigerant (R600a), foam insulation and packaging
  • Pharmacy refrigerator/freezer toolkit and temperature logs
  • Two year parts and labor warranty, plus an additional three year compressor parts warranty
  • Note: This unit must have 4” clearance on sides and back for adequate ventilation

Accessories:

10.5 Basket

 ABT-SLD BSKT-FULL-10.5



10.5 Bottom Basket

 ABT-BSKT-BASE-FIXED-10.5

  • Exterior dimensions:
    Width: 23¾”
    Depth: 26½”
    Height: 59″
  • UL/C-UL listed
  • Cycle defrost
  • Energy Star Certified
  • 115V, 60 Hz, 1/3 HP, 2.3 Amps
  • Shipping weight:  183 lbs.
  • Microprocessor temperature controller
  • Digital temperature display with battery back-up to support temperature monitoring and alarms
  • Audible and visual  high and low temperature alarms
  • 2 probes; 1 in air and 1 in sample bottle
  • Remote alarm contacts
  • Adjustable operating temperature range:  36°F to 46°F (2°C to 8°C)
  • Temperature monitor device (TMD) complies with the current CDC guidelines, with 3 years certification of calibration, “buffered” probe in the product simulated solution, min/max memory. F/C switchable, field installable, and visual & audible temp alarm
