23 Cu. Ft. Premier Stainless Steel Auto Defrost Pharmacy Freezer (-4°F Operation)

Product Number: PH-ABT-HC-SSP-23FA



The Premier Stainless Steel Pharmacy Freezers feature a microprocessor temperature controller, allowing for precise temperature control, recovery and maintenance versus mechanical style thermostats

Critical samples and supplies are security backed with an extensive package of temperature security and alarm features.

DISCLAIMER: Auto defrost freezers incorporate an electric heater installed on the evaporator that assist in the removal of the frost and ice. Although the heater helps speed up the frost and ice removal, it can raise the temperatures within the freezer.

Environmentally friendly, natural hydrocarbon (HC) refrigerants (not containing hydrofluorocarbons) vastly reduce global-warming potential (GWP) while meeting new EPA/SNAP mandates and UL, ASHRAE compliance guidelines

Request a Custom Quote

Get pricing and availability for this product

Product Inquiry
Gelu

Ask Gelu about the PH-ABT-HC-SSP-23FA

Here are common questions and answers about this product

Gelu is on every product pageJust ask a question, anytime
What's the adjustable temperature range on this freezer?

The adjustable operating temperature range is 5°F – -13°F (-15°C – -25°C).

Temp Controller tab
What are the exterior dimensions and shipping weight?

Width is 26 7/8", depth is 35 3/4", and height is 83 1/4" with casters or 77 1/2" without casters. Shipping weight is 327 lbs.

Specifications tab
How many shelves come with it, and are they adjustable?

It includes 3 adjustable shelves.

Datasheet
What are the electrical requirements?

It runs on 115V, 60 Hz, 8 Amps, 3/4 HP.

Specifications tab
What refrigerant does it use, and is it certified?

It uses hydrocarbon natural refrigerant (R290). The unit is Intertek ETL Listed and Green Leaf Verified.

Certifications
What does the warranty cover?

It carries a 2 year parts and labor warranty, plus an additional 3 year compressor parts warranty.

Details tab
Answers come from this product's record and datasheet. Settings and procedures come from the owner's manual.

Product details for the PH-ABT-HC-SSP-23FA

The description, performance figures and controller details, straight from the datasheet.

Need the full datasheet? Use View / Print Product Information above.
Details
  • 2 probes; 1 in air and 1 in sample bottle
  • Probe attached to evaporator for defrost termination sensing Sensor error alarm
  • Continuous product (simulated) temperature display Remote alarm contacts
  • Keyed door lock
  • Magnetic door gaskets for positive seal Integrated door handle
  • LED interior lights are safety shielded and switch controlled
  • Probe access port (3/4″)
  • Stainless steel exterior
  • White-powder coated aluminum interior with 304 stainless steel floor
  • Easily cleaned smooth interior Hydrocarbon natural refrigerant (R290)
  • 2 year parts and labor warranty, plus an additional 3 year compressor parts warranty
  • Auto defrost
  • 4 swivel casters (5 3/4″)
  • Exterior dimensionsWidth: 26 7/8”Depth: 35 ¾”Height: 83 1/4” with casters; 77 1/2” without casters
  • 115V, 60 Hz, 8 Amps, 3/4 HP
  • ETL listed
  • Shipping weight: 327 lbs.
  • Microprocessor temperature controller
  • Digital temperature display
  • Audible and visual high and low temperature alarms
  • 2 probes; 1 in air and 1 in sample bottle
  • Calibrated using a NIST traceable device, certificate included
  • Remote alarm contacts
  • Adjustable operating temperature range: 5°F – -13°F (-15°C – -25°C)

Related Products

American BioTech Supply HC-SSP-49FA medical refrigerator, external view featuring a full-height solid door design with stainless steel finish, built for high-volume pharmaceutical and clinical storage
