A white upright 4 cu. ft. undercounter pharmacy freezer labeled “Med Freezer” and “American BioTech Supply” on the front. The control panel and digital display are on top. A green “eco friendly” sticker is near the bottom right corner. The freezer stands on four small black feet.
A white upright 4 cu. ft. undercounter pharmacy freezer labeled “Med Freezer” and “American BioTech Supply” on the front. The control panel and digital display are on top. A green “eco friendly” sticker is near the bottom right corner. The freezer stands on four small black feet.
PH-ABT-HC-UCFS-0440 SpecSheet PH-ABT-HC-UCFS-0440 Ext Cutsheet PH-ABT-HC-UCFS-0440 Int Cutsheet

4 Cu. Ft. Capacity Premier Pharmacy Undercounter Freezer Freestanding (-40°F Operation)

Product Number: PH-ABT-HC-UCFS-0440

EnergyStarulGreen-Leaf-ABS

The Premier Pharmacy Freestanding Undercounter Freezers feature a microprocessor temperature controller and display, allow for precise temperature control, verification and recovery versus mechanical style thermostats. Critical samples and supplies are security backed with an extensive package of audible and visual alarms

Periodic defrosting is required.

The Freestanding models (“UCFS”) require 4” of clearance around back and sides of the unit for proper ventilation. Improper installation will void the warranty and will lead to temperature maintenance issues, overheating and possible failure.

Environmentally friendly, natural hydrocarbon (HC) refrigerants (not containing hydrofluorocarbons) vastly reduce global-warming potential (GWP) while meeting new EPA/SNAP mandates and UL, ASHRAE compliance guidelines.

For more information on Vaccine Storage: Vaccine Storage

The acceptable temperature ranges for vaccine storage are 36°F to 46°F (or 2°C to 8°C) in the refrigerator and -58°F to 5°F (or -50°C and -15°C) in the freezer.

Product Inquiry
Details
  • Three adjustable shelves with guard rail on back to prevent product from being pushed against the back wall
  • Bottom footed shelf to allow air circulation
  • Back wall evaporator cover
  • Keyed door lock
  • Magnetic door gasket for positive seal
  • Recessed door handle
  • Leveling legs
  • LED interior light
  • Pharmacy refrigerator/freezer toolkit and temperature logs
  • HFC-free refrigerant (R290), foam insulation and packaging
  • Two year parts and labor warranty, plus an additional three year compressor parts only warranty
  • Pyxis®, Omnicell® and AcuDose RX® compatible
  • Note: This unit must have 4” clearance on sides and back for adequate ventilation



  • Exterior dimensions:
    Width: 23 ¾”
    Depth: 24″
    Height: 32 1/8″
  • Manual defrost
  • 115V, 60 Hz, 2.2 Amps, 1/4 HP
  • UL/C-UL listed
  • Shipping weight: 128 lbs.
  • Microprocessor temperature controller
  • Digital temperature display and Alarm Module with battery back-up to support temperature monitoring and alarms
  • Audible and visual high and low temperature alarms
  • Remote alarm contacts
  • 2 probes; 1 in air and 1 in glycol bottle
  • Adjustable operating temperature range: -35°F to -45°F (-37°C to -43°C)
  • Calibrated using a NIST traceable device, certificate included
