1.7 Cu. Ft. Freestanding Vaccine Countertop Freezer Certified to NSF/ANSI 456

Product Number: PH-ABT-NSF-UCFS-0120

These premier freestanding countertop freezers are designed in accordance with the NSF/ANSI 456 Standard for Vaccine Storage. Freezers protect pharmaceuticals at optimal temperatures, preventing waste and allowing for peak delivery.

These models utilize microprocessor controllers and feature temperature alarms, remote alarm contacts, LED interior lighting, and probe access ports with included probes. American Biotech Supply Vaccine Storage Refrigerators utilize HFC-free refrigerant for environmental health and energy efficiency

For more information on Vaccine Storage: Vaccine Storage
The acceptable temperature ranges for vaccine storage are 36°F to 46°F (or 2°C and 8°C) in the refrigerator and -58°F and 5°F (or -50°C and -15°C) in freezers.

*-one or more of these certifications may apply to this unit.

Request a Custom Quote

Get pricing and availability for this product

Product Inquiry
Gelu

Ask Gelu about the PH-ABT-NSF-UCFS-0120

Here are common questions and answers about this product

Gelu is on every product pageJust ask a question, anytime
What temperature range can I set this freezer to?

The temperature setpoint range is -15°C to -28°C. Per the Temp Controller tab, controller settings must remain unaltered to ensure thermal performance compliant with NSF/ANSI 456 requirements.

Temp Controller tab
How much clearance does it need around the cabinet?

4″ of clearance on all sides must be maintained for adequate ventilation. It sits on leveling legs.

Details tab
What does the warranty cover?

It carries a two (2) year parts and labor warranty, excluding display probe calibration, plus a five (5) year compressor warranty.

Details tab
How much does the unit weigh and what does it weigh shipped?

Product weight is 66 lbs. and shipping weight is 94 lbs.

Details tab
What alarms are included and is there a way to connect to external monitoring?

It has High / Low temperature alarms compliant with the alarm requirements defined in the NSF/ANSI 456 Standard for Vaccine Storage. The Summary notes remote alarm contacts and a probe access port with included probes, and the Details tab lists a rear wall external probe access port (23/32″ dia.).

Temp Controller tab
What certifications does this freezer carry?

It is ENERGY STAR Certified, Intertek ETL Listed, Green Leaf Verified, Certified to NSF/ANSI 456 (vaccine storage), and UL/cUL Listed (US & Canada).

Certifications
What does NSF/ANSI 456 certified mean, and who is it for?

NSF/ANSI 456 is the vaccine storage standard from NSF International, which sets performance and construction requirements for vaccine refrigerators and freezers. A certified unit like this one is tested by an independent third-party lab under protocols that go far beyond those for a standard pharmacy refrigerator: vaccine simulation devices are placed at worst-case positions inside the unit and temperatures are recorded 30 to 90 times faster than a typical data logger. It holds temperature within ±0.5°C, with forced-air circulation and dual temperature monitoring with audible and visual alarms. It is for anyone who stores vaccines or other temperature-sensitive pharmaceuticals and needs certified protection through heavy use and frequent door openings: pharmacies, clinics, physician offices, hospitals and immunization programs.

American Biotech Supply
Answers come from this product's record and datasheet. Settings and procedures come from the owner's manual.

Product details for the PH-ABT-NSF-UCFS-0120

The description, performance figures and controller details, straight from the datasheet.

Need the full datasheet? Use View / Print Product Information above.
Details
Description
Single Solid Door Pharmacy/Vaccine Undercounter Refrigerator Freestanding Left Hinged
Operational environment
Indoor use only. Optimal operating range: +18°C to +26°C (+65°F to +78°F), <70% RH
Storage capacity
1 cu. ft. gross volume
Door
One swing solid door, self-closing, left hinged, non-reversible, magnetic sealed gasket, keyed lock
Shelves
Three shelves (two adjustable/one fixed) with guard rail on back
Mounting and Installation
Leveling legs. Note: 4″ of clearance on all sides must be maintained for adequate ventilation
Interior lighting
N/A
Airflow management
Forced Air technology, patent pending
External probe access
Rear wall port (23/32″) dia.
Insulation
Cabinet is foamed-in-place with EPA compliant high density urethane foam
Exterior materials
White powder coated steel
Access control
Pyxis®, Omnicell® and AcuDose RX® compatible
General warranty
Two (2) years parts and labor warranty, excluding display probe calibration
Compressor warranty
Five (5) years compressor warranty
Product Weight
66 lbs.
Shipping Weight
94 lbs.
Rated Amperage
0.9 A max
Agency Listing and Certification
Pharmacy refrigerator/freezer toolkit and temperature logs
Uniformity¹ (Cabinet air)
+/- 1.5°C
Stability² (Cabinet air)
+/- 0.7°C
Maximum temperature variation
+/- 1.8°C
Temperature rise after 8 sec door openings
Temperature did not exceed 6.8°C at any probe for all required NSF/ANSI 456 testing protocolsᶟ
Recovery after 3 min door opening
All probes recover to under 8°C within 5.5 min.
Energy consumption
0.71 KWh/day⁴
Average heat rejection
1.01 KWh/day (144 BTU/h)⁴
Noise pressure level (dBA)
34 or less installed
Pull down time to nominal operating temp
35 min
Controller technology
Parametric, microprocessor, LED display with 0.1°C resolution
Temperature setpoint range
-15°C to -28°C (Controller settings must remain unaltered to ensure thermal performance compliant with NSF/ANSI 456 requirements)
Calibration
Calibrated using a NIST traceable device, certificate included
Alarms
High / Low temperature, compliant with alarm requirements defined in the NSF/ANSI 456 Standard for Vaccine Storage
Simulator ballast
Glass bead thermal media
