American BioTech Supply HC-2586-TS medical refrigerator, external view featuring a triple solid door configuration with a high-capacity design for storing vaccines, pharmaceuticals, and laboratory materials
A large, white Ultra-Low Temperature Freezer stands with its door open, revealing five horizontal interior drawers. It features a gray base with ventilation grilles and wheels, plus a thick-sealed door with a curved handle and lock.
A large, upright Ultra-Low Temperature Freezer with the door open reveals six empty horizontal shelves inside. The metallic gray unit features ventilation grilles at the bottom, a large circular handle on the door, and small wheels for mobility.
A digital control panel on the Ultra-Low Temperature Freezer displays “ZONE 1: P1” and a large reading of -86.6°C, with icons for settings, home, and warning. The metallic frame features a vertical temperature scale on the left.

Enter your email to receive this document

This field is for validation purposes and should be left unchanged.
Name(Required)
Email(Required)
By submitting a request, you agree and consent to the use of your information in accordance with our Privacy Policy


You maybe required to confirm your email address within 2hrs to complete this request. Check your inbox.

25 Cu. Ft. TempLog Premier Ultra Low Temperature Touchscreen Freezer Dual Voltage

Product Number: ABT-HC-2586-TS
ALSO AVAILABLE IN THESE SIZES17 21 CU. FT.

Transform your laboratory’s sample preservation with the ABT-HC-2586-TS ultra-low temperature freezer, engineered to protect your most valuable research materials. This 25 cu.ft. capacity system accommodates up to 480 2-inch storage boxes while maintaining temperatures as low as -86°C with remarkable energy efficiency. The combination of five insulated inner doors and foamed-in-place high-density urethane insulation ensures your samples remain at optimal preservation temperatures.

The ABT-HC-2586-TS puts complete control at your fingertips through its intuitive 11-inch color touchscreen interface. Monitor real-time temperatures, configure customizable alarms with adjustable delays and volumes, and export comprehensive data logs for compliance documentation. The integrated 4-20mA output enables seamless connection to facility monitoring systems, while the 12V battery backup maintains all critical monitoring and alarm functions during power interruptions, giving you peace of mind that your samples remain monitored 24/7.

Backed by exceptional warranties including a five-year parts and labor plus a seven-year warranty on the compressors, the ABT-HC-2586-TS represents a smart long-term investment. The unit arrives ready for immediate installation with both 120V and 240V power cords included, mounted on four heavy-duty locking casters for positioning flexibility. Using environmentally responsible natural hydrocarbon refrigerants, this freezer delivers sustainable operation while reducing long-term operational costs through its highly efficient dual variable speed compressor system.

Key Features

  • Variable speed compressor technology
  • Intuitive color touchscreen display
  • Five insulated inner doors maintain temperature stability during access
  • Natural hydrocarbon refrigerants for sustainable operation and efficiency
  • Maximized storage space with the capacity to store 480 2-inch storage boxes

Benefits

  • Simplify installation with dual voltage capability
  • Maintain sample integrity with five inner doors minimizing temperature loss
  • Track compliance effortlessly through comprehensive data logging and export features
  • Enhance energy efficiency using natural hydrocarbon refrigerants
  • Enjoy a protective 5-year parts and labor warranty alongside a 7-year compressor warranty

Request a Custom Quote

Get pricing and availability for this product

Gelu

Ask Gelu about the ABT-HC-2586-TS

Here are common questions and answers about this product

Gelu is on every product pageJust ask a question, anytime
What temperature range does this freezer operate in?

The adjustable temperature range is -86°C to -50°C.

Refrigeration System tab
How many storage boxes can it hold?

It has capacity for 480 2″ boxes (30 UF442 racks).

Details tab
What are the exterior dimensions and weight?

Exterior width is 49″, depth is 36.3″, and height is 79.6″. Product weight is 730 lbs. and shipping weight is 845 lbs.

Details tab
What are the electrical requirements and what plugs are included?

It requires dual voltage 110-120V 15A (minimum) or 208-240V AC 15A (minimum), with rated amperage of 10A at 120V and 6A at 240V. Two detachable cords of minimum 8′ length are supplied: 120V (NEMA 5-15 Plug) and 240V (NEMA 6-15 Plug).

Details tab
What refrigerants does it use?

The system uses R290 / R170 natural hydrocarbon refrigerants.

Refrigeration System tab
What warranty coverage is provided?

The unit comes with a five (5) year parts and labor warranty and a seven (7) year compressor warranty.

Details tab
Answers come from this product's record and datasheet. Settings and procedures come from the owner's manual.

Product details for the ABT-HC-2586-TS

The description, performance figures and controller details, straight from the datasheet.

Need the full datasheet? Use View / Print Product Information above.
Storage capacity (cu. ft)
25 Cu. Ft. Capacity
Door
One solid exterior door, right hinged, not reversible; Five insulated inner doors
Shelves
Four adjustable, stainless steel standard, tested to 160 lbs. (optional configurations available)
Box Capacity
Qty. 480 2″ boxes (30 UF442 racks)
Mounting
Four heavy duty swivel casters with locks
External probe access
1/2″ diameter port; access from back of unit to interior left side
Insulation
Foamed-in-place EPA compliant high density urethane foam
Exterior materials
Powder coated Steel
Insulation
Cabinet is foamed-in-place with EPA compliant high density urethane foam
Interior lighting
Non-applicable
Access Control
Key lock on exterior door handle
General warranty
Five (5) year parts and labor warranty
Compressor warranty
Seven (7) years compressor warranty
Product Weight (lbs.)
730
Shipping Weight (lbs.)
845
 Exterior Width (in)
49″
 Exterior Depth (in)
36.3″
 Exterior Height (in)
79.6″
Rated Amperage
10A (120V), 6A (240V)
Power Plug/Power Cord
Two detachable cords supplied, min. 8′ length: 120V (NEMA 5-15 Plug) and 240V (NEMA 6-15 Plug)
Facility Electrical Requirement
Dual Voltage 110-120V 15A (minimum) or 208-240V AC 15A (minimum)
Agency Listing and Certification
UL/C-UL listed. Certified to UL 60335-2-89 Safety Standard
Vacuum Relief Port:
Includes heated vacuum relief port for pressure equalization reducing wait times between door openings
Average heat rejection (BTU/h):
1668 BTU/h
Energy Consumption (kWh/Day/CUFT)
As low as 0.41 kWh/day/cu.ft.
Adjustable Temperature Range
-86°C to -50°C
Warm-up times:
180+ minutes -80°C to -50°C°
Refrigerant
R290 / R170
Condenser:
Tube and Fin design, EC fan, easy clean removable filter
Evaporator:
Cold wall (Natural convection)
Compressor:
Two ea. variable speed hermetic reciprocating



Controller technology
Microprocessor with color touchscreen (11in) input and display, C° or F°
Battery Backup
12V high capacity battery for controller and touchscreen display: temperature monitoring, alarms, and event logging active
External alarm connection
State switching remote alarm contacts
Digital Communication
4-20mA output for temperature monitoring
Alarms
  Audible and Visual Alarms: customizable sounds and volumes; mute with visual persistence; ring-back functionality re-engages audible alarm after
pre-set delay if alarm condition persists. Adjustable delays for door, temperature, power loss.
Disclaimers
  Indoor use only, +18C to +26C (+65F to +78F), <70% RH.
Specifications are subject to change. Backup battery maintains display, data logging, and alarms. Cooling capability is not maintained
without external generator.
Optional Accessories
  Removable storage racks, Precision fit rack system (in place of shelves), storage boxes, Wi-Fi data logger, additional shelves,
additional chamber temperature (sample) probe.
