American Biotech Supply ABT-HC-PL-49 plasma freezer with solid insulated door, digital temperature control, and heavy-duty handle, designed for high-volume plasma storage in clinical and laboratory environments. American Biotech Supply ABT-HC-PL-49 plasma freezer with solid insulated door, digital temperature control, and heavy-duty handle, designed for high-volume plasma storage in clinical and laboratory environments.
American Biotech Supply ABT-HC-PL-49 plasma freezer with solid insulated door, digital temperature control, and heavy-duty handle, designed for high-volume plasma storage in clinical and laboratory environments.
American Biotech Supply ABT-HC-PL-49 plasma freezer with solid insulated door, digital temperature control, and heavy-duty handle, designed for high-volume plasma storage in clinical and laboratory environments.

49 Cu. Ft. Premium Laboratory Glass Door Refrigerator

Product Number: ABT-HC-PL-49

EnergyStarGreen-Leaf-ABS intertek-etl-listed-us-mark-seeklogo31 (002)


Transform your laboratory’s cold storage capabilities with the ABT-HC-PL-49, a premium 49 cubic foot glass door refrigerator that combines whisper-quiet operation with exceptional energy efficiency. This advanced unit consumes just 1.47 KWh per day while maintaining laboratory-grade temperature control, helping you reduce operational costs without compromising performance. The variable speed compressor technology automatically adjusts cooling output based on demand, delivering significant energy savings compared to traditional fixed-speed systems while operating at an impressively quiet 38 dBA or less.

The ABT-HC-PL-49 puts you in complete control of your temperature-sensitive materials with its sophisticated microprocessor-based PID controller and comprehensive alarm system. Battery backup ensures continuous monitoring even during power outages, while visual and audible alarms alert you to any temperature excursions, door ajar conditions, or system issues. The adjustable temperature range of 1°C to 10°C accommodates diverse storage requirements, and the LCD display provides clear, real-time temperature information at a glance.

Designed for maximum usability and longevity, the ABT-HC-PL-49 features double swing glass doors that open from either side for convenient access in any laboratory layout. Ten adjustable shelves with protective rear guard rails organize your specimens efficiently within the generous 49 cubic foot interior. The durable white powder coated steel construction and EPA-compliant high-density urethane foam insulation ensure years of reliable service, backed by an exceptional seven-year compressor warranty and two-year comprehensive coverage that demonstrates our confidence in this premium refrigerator’s quality.

Key Features

  • Energy-efficient operation at 1.47 KWh per day with 465 BTU/hr average heat rejection
  • Battery backup system maintains alarms and temperature monitoring during power failures
  • Adjustable temperature range from 1°C to 10°C with PID microprocessor control
  • EPA SNAP compliant R600a refrigerant with hermetic variable speed compressor
  • RS-485 MODBUS communication and USB port for data transfer and updates

Benefits

  • Slash energy costs while meeting sustainability goals with ultra-efficient 1.47 KWh/day consumption
  • Protect valuable research materials with battery-backed monitoring that never sleeps
  • Create a more pleasant work environment with whisper-quiet 38 dBA operation
  • Simplify compliance documentation with built-in data logging and USB data transfer capabilities
  • Maximize storage flexibility with ten adjustable shelves in a spacious 49 cubic foot capacity
  • Reduce long-term ownership costs with a seven-year compressor warranty and durable construction
  • Accelerate daily workflows with 70-minute pull-down time and convenient double-door access
  • Ensure specimen integrity with ±1.2°C uniformity and ±1.0°C stability performance

Request a Custom Quote

Get pricing and availability for this product

Storage capacity (cu. ft) 49
Door Double Swing Glass Right and Left Hinged Door(s)
Shelves Ten adjustable shelves with guard rail on back
Drawers Optional pull-out drawers available
Mounting and Installation 4 preinstalled swivel casters, front casters locking
Interior lighting Shielded, switched LED lighting, full coverage, balanced spectrum
Airflow Management Forced Air technology, patent pending
External probe access Rear wall port (3/4″) dia.
Insulation Cabinet is foamed-in-place with EPA compliant high density urethane foam
Exterior materials White powder coated steel
Access control Key Lock
General warranty Two (2) years parts and labor warranty
Compressor warranty Seven (7) years compressor warranty
Product Weight (lbs) 581
Shipping Weight (lbs) 700
 Exterior Width (in)  54
 Exterior Depth (in)  35.75
 Exterior Height (in)  81.5
Rated Amperage 4.5 Amps
Power Plug/Power Cord NEMA 5-15 plug
Facility Electrical Requirement 110-120V AC: 15 A (minimum)
Agency Listing and Certification ETL, C-ETL listed and certified to UL471 standard, hydrocarbon refrigerant safety, Energy Star Certified

Accessory:

ABT-DWRKIT-PL49



Uniformity (Cabinet air) ±1.2
Stability (Cabinet air) ±1.0
Maximum temperature variation (Cabinet air) ±1.6
Stability² (Simulator ballast) Non-applicable
Stability² (Simulator bag) Non-applicable
Temperature Rise after Short Door Openings Non-applicable
Recovery after Short Door Openings Non-applicable
Energy Consumption (KWh/day) 1.47
Average Heat Rejection (BTU/hr) 465
Noise Pressure Level (dBA) 38 or less installed
Pull down time to nominal operating temp 70 min
Compressor  Hermetic, variable speed (VSC). Rated speed range: 1300-4000 rpm
Refrigerant  EPA SNAP compliant, R600a
Condenser  Anti-fouling tube and grid design, ultra-quiet multi-speed fan
Evaporator  Fin and tube design, high efficiency fan
Defrost  Cycle optimized, zero energy



Controller technology Proportional Integral Derivative (PID) microprocessor with LCD display
Battery Backup  24V high-capacity battery, controller, all alarms active, temperature monitoring DAQ and
event logging active on battery backup
Display technology Non-applicable
Digital Communication RS-485 (MODBUS)
Data Transfer USB port for data transfer and software updates
Chart Recorder Non-applicable
Adjustable Temperature Range 1°C to 10°C
External alarm connection State switching remote alarm contacts
Alarms Alarm logging (last 100 entries) with Visual and audible indicators: Power failure, Temperature
sensor failure, Battery voltage monitor and replacement, High / Low temperature, Door ajar.
Controller probe Bottle with glass bead thermal media
