20 Cu. Ft. General Purpose Refrigerator & Freezer Combination

Product Number: ABT-HC-RFC20A
ALSO AVAILABLE IN THESE SIZES3 14 CU. FT.

The General Purpose Dual Temperature units meet and exceed the specifications of most general-purpose units, providing both refrigerator and freezer compartments with standard analog dial temperature thermostats. Units are intended for general purpose applications only where precise temperature control and maintenance are not essential and there are no requirements for temperature alarms.

Auto defrost freezer compartments have programmed defrost cycles that will reach air temperatures of approximately 0 degrees Celsius.

Environmentally friendly, natural hydrocarbon (HC) refrigerants (not containing hydrofluorocarbons) vastly reduce global-warming potential (GWP) while meeting new EPA/SNAP mandates and UL, ASHRAE compliance guidelines.

DISCLAIMER: Auto defrost freezers incorporate an electric heater installed on the evaporator that assist in the removal of the frost and ice. Although the heater helps speed up the frost and ice removal, it can raise the temperatures within the freezer.

Request a Custom Quote

Get pricing and availability for this product

Product Inquiry
Gelu

Ask Gelu about the ABT-HC-RFC20A

Here are common questions and answers about this product

Gelu is on every product pageJust ask a question, anytime
What are the refrigerator and freezer temperature ranges?

The refrigerator range is 0°C to 10°C, and the freezer chamber is -15°C to -10°C with two auto defrost cycles warming to 0°C per day.

Temp Controller tab
How is the 20 cu ft capacity split between the refrigerator and freezer?

The unit provides 15 cu ft of refrigerator space and 5 cu ft of freezer space.

Details tab
What are the exterior dimensions and shipping weight?

Exterior dimensions are 30″ wide, 34 1/8″ deep, and 69″ high. Shipping weight is 231 lbs.

Specifications tab
What are the electrical requirements?

The unit runs on 115V, 60 Hz and draws 3 Amps.

Specifications tab
What refrigerant does this unit use?

It uses R600a, a natural hydrocarbon (HC) refrigerant that does not contain hydrofluorocarbons, helping reduce global-warming potential while meeting EPA/SNAP mandates and UL, ASHRAE compliance guidelines.

Summary
What shelving comes with the unit and are there probe access ports?

The refrigerator has three shelves (one fixed, two adjustable) and the freezer has one fixed shelf. There are two 3/8″ probe access ports, one in the refrigerator and one in the freezer.

Details tab
Answers come from this product's record and datasheet. Settings and procedures come from the owner's manual.

Product details for the ABT-HC-RFC20A

The description, performance figures and controller details, straight from the datasheet.

Need the full datasheet? Use View / Print Product Information above.
Details
  • 20 Cu. Ft. (15 Cu. Ft Refrigerator/5 Cu. Ft. Freezer)
  • Three shelves, refrigerator (one fixed, two adjustable); one fixed shelf, freezer
  • Magnetic door gasket for positive seal
  • Heavy duty door handles
  • Leveling legs
  • Interior refrigerator light
  • Two probe access ports (3/8″); one, refrigerator/one, freezer
  • White textured cabinet and door
  • High density urethane foam cabinet and door insulation
  • Hydrocarbon, natural refrigerant (R600a)
  • Two year parts and labor warranty, plus an additional three year compressor parts warranty
  • Exterior dimensionsWidth: 30″Depth: 34 1/8″Height: 69″
  • Auto defrost (Freezer); Cycle defrost (Refrigerator)
  • 115V, 60 Hz, 3 Amps
  • Shipping weight: 231 lbs.
  • Mechanical thermostat
  • Refrigerator temperature range : 0°C to 10°C
  • Freezer chamber: -15°C to -10°C with two auto defrost cycles warming to 0°C per day

Related Products

ABT-RFC30M medical-grade refrigerator-freezer combo by American Biotech Supply, shown in a product listing view for clinical cold storage applications
