10.5 Cu. Ft. Compact Solid Door Refrigerator Certified to NSF/ANSI 456 Pharmacy

Product Number: PH-ABT-NSF-10PS

These compact refrigerators are designed in accordance with the NSF/ANSI 456 Standard for Vaccine Storage. Refrigerators protect pharmaceuticals at optimal temperatures, preventing waste and allowing for peak delivery.

These solid door compact refrigerators utilize microprocessor controllers and feature temperature alarms, remote alarm contacts, LED interior lighting, and probe access ports. American Biotech Supply Vaccine Storage Refrigerators utilize HFC-free refrigerant for environmental health and energy efficiency.

For more information on Vaccine Storage: Vaccine Storage
The acceptable temperature ranges for vaccine storage are 36°F to 46°F (or 2°C and 8°C) in the refrigerator and -58°F and 5°F (or -50°C and -15°C) in freezers.

*-one or more of these certifications may apply to this unit.



Request a Custom Quote

Get pricing and availability for this product

Product Inquiry
Gelu

Ask Gelu about the PH-ABT-NSF-10PS

Here are common questions and answers about this product

Gelu is on every product pageJust ask a question, anytime
What temperature setpoint range does the controller allow?

The temperature setpoint range is 1°C to 10°C. The setpoint must remain unaltered from the factory setting to remain compliant with NSF/ANSI 456 Standard for Vaccine Storage requirements.

Temp Controller tab
How much clearance is needed around the unit, and how is it moved?

4″ of clearance on all sides must be maintained for adequate ventilation. The unit has low profile roller wheels and leveling legs.

Description tab
How many shelves come with this refrigerator?

It includes seven shelves (six adjustable/one fixed) with a guard rail on back.

Description tab
What are the electrical requirements and plug type?

The unit is rated at 2.3 Amps and requires 110-120V AC, 15 A (minimum) facility electrical service. It uses a NEMA 5-15 plug with an 8 to 10 ft typical cord that conforms to UL471 requirements and carries a vaccine storage power cord warning label.

Description tab
What warranty is included?

It comes with a two (2) years parts and labor warranty, excluding display probe calibration, and a five (5) years compressor warranty.

Description tab
What certifications does this refrigerator carry?

It is ENERGY STAR Certified, Intertek ETL Listed, Intertek Sanitation Certified, Green Leaf Verified, Certified to NSF/ANSI 456 (vaccine storage), and UL/cUL Listed (US & Canada).

Certifications
What does NSF/ANSI 456 certified mean, and who is it for?

NSF/ANSI 456 is the vaccine storage standard from NSF International, which sets performance and construction requirements for vaccine refrigerators and freezers. A certified unit like this one is tested by an independent third-party lab under protocols that go far beyond those for a standard pharmacy refrigerator: vaccine simulation devices are placed at worst-case positions inside the unit and temperatures are recorded 30 to 90 times faster than a typical data logger. It holds temperature within ±0.5°C, with forced-air circulation and dual temperature monitoring with audible and visual alarms. It is for anyone who stores vaccines or other temperature-sensitive pharmaceuticals and needs certified protection through heavy use and frequent door openings: pharmacies, clinics, physician offices, hospitals and immunization programs.

American Biotech Supply
Answers come from this product's record and datasheet. Settings and procedures come from the owner's manual.

Product details for the PH-ABT-NSF-10PS

The description, performance figures and controller details, straight from the datasheet.

Need the full datasheet? Use View / Print Product Information above.
Description
Description
Single solid Door Pharmacy/Vaccine Refrigerator Freestanding
Operational environment
Indoor use only. Optimal operating range: +18°C to +26°C (+65°F to +78°F), 70% RH
Storage capacity
10.5 cu. ft. gross volume
Door
One swing solid door, self-closing, right hinged, non-reversible, magnetic sealed gasket, keyed lock
Shelves
Seven shelves (six adjustable/one fixed) with guard rail on back
Mounting and Installation
Low profile roller wheels and leveling legs. Note: 4″ of clearance on all sides must be maintained for adequate ventilation
Interior lighting
Shielded, switched LED lighting, full coverage, balanced spectrum
Airflow management
Forced Air technology, patent pending
External probe access
Rear wall port (3/8″) dia.
Insulation
Cabinet is foamed-in-place with EPA compliant high density urethane foam
Exterior materials
White powder coated steel
Access control
Pyxis®, Omnicell® and AcuDose RX® compatible
General warranty
Two (2) years parts and labor warranty, excluding display probe calibration
Compressor warranty
Five (5) years compressor warranty
Product Weight
154 lbs.
Shipping Weight
189 lbs.
Rated Amperage
2.3 Amps
Power Plug/Power Cord
NEMA 5-15 plug, 8 to 10 ft typical, conforms to UL471 requirements, Vaccine storage power cord warning label
Facility Electrical Requirement
110-120V AC: 15 A (minimum)
Agency Listing and Certification
Certified in accordance with the NSF/ANSI 456 Standard for Vaccine Storage. UL, C-UL, ETL, C-ETL listed, Energy Star Certified Pharmacy refrigerator/freezer toolkit and temperature logs

Accessories:

10.5 Basket ABT-SLD BSKT-FULL-10.5



10.5 Bottom Basket ABT-BSKT-BASE-FIXED-10.5

Uniformity¹ (Cabinet air)
+/- 1.0°C
Stability² (Cabinet air)
+/- 0.8°C
Maximum temperature variation (Cabinet Air)
+/-1.3°C
Temperature rise after 8 sec door openings
Temperature did not exceed 5.8°C at any probe for all required NSF/ANSI 456 testing protocolsᶟ
Recovery after 3 min door opening
All probes recover to under 8°C within 3.5 min.
Energy consumption
2.42 KWh/day⁴
Average heat rejection
3.27 KWh/day (465 BTU/h)⁴
Noise pressure level (dBA)
49 or less installed
Pull down time to nominal operating temp
25 min.
Controller technology
Parametric, microprocessor, LED display with 0.1°C resolution
Temperature setpoint range
1°C to 10°C (Setpoint must remain unaltered from the factory setting to remain compliant with NSF/ANSI 456 Standard for Vaccine Storage requirements)
Calibration
Calibrated using a NIST traceable device, certificate included
External alarm connection
State switching remote alarm contacts
Alarms
Visual and audible indicators, High / Low temperature, compliant with alarm requirements defined in the NSF/ANSI 456 Standard for Vaccine Storage
Simulator ballast
Glass bead thermal media
