A tall, white medical refrigerator on wheels displays a digital temperature screen reading 4.0°C. The door has a large handle, “Med Fridge” label, and an ABS logo on top. Vents and a circular “We Care for the Planet” sticker appear near the base. White ABS laboratory refrigerator with glass door and digital display set to 4.0 degrees, featuring four wire shelves and black casters with storage drawers.
A tall, white medical refrigerator on wheels displays a digital temperature screen reading 4.0°C. The door has a large handle, “Med Fridge” label, and an ABS logo on top. Vents and a circular “We Care for the Planet” sticker appear near the base.
White ABS laboratory refrigerator with glass door and digital display set to 4.0 degrees, featuring four wire shelves and black casters with storage drawers.
PH-ABT-NSF-12S DataSheet

Enter your email to receive this document

This field is for validation purposes and should be left unchanged.
Name(Required)
Email(Required)
By submitting a request, you agree and consent to the use of your information in accordance with our Privacy Policy


You maybe required to confirm your email address within 2hrs to complete this request. Check your inbox.

12 Cu. Ft. Premier Pharmacy Solid Door Refrigerator Certified to NSF/ANSI 456

Product Number: PH-ABT-NSF-12S
ALSO AVAILABLE IN THESE SIZES16 23 26 49 CU. FT.

These premier pharmacy solid door upright refrigerators are designed in accordance with the NSF/ANSI 456 Standard for Vaccine Storage. Refrigerators protect pharmaceuticals at optimal temperatures, preventing waste and allowing for peak delivery.

These solid door refrigerators utilize microprocessor controllers and feature temperature alarms, remote alarm contacts, LED interior lighting, and probe access ports. American Biotech Supply Vaccine Storage Refrigerators utilize HFC-free refrigerant for environmental health and energy efficiency.

For more information on Vaccine Storage: Vaccine Storage
The acceptable temperature ranges for vaccine storage are 36°F to 46°F (or 2°C and 8°C) in the refrigerator and -58°F and 5°F (or -50°C and -15°C) in freezers.

*-one or more of these certifications may apply to this unit.



Request a Custom Quote

Get pricing and availability for this product

Product Inquiry
Gelu

Ask Gelu about the PH-ABT-NSF-12S

Here are common questions and answers about this product

Gelu is on every product pageJust ask a question, anytime
What temperature range can I set this refrigerator to?

The temperature setpoint range is 1°C to 10°C. The setpoint must remain unaltered from the factory setting to remain compliant with the NSF/ANSI 456 Standard for Vaccine Storage requirements.

Temp Controller tab
What are the shelving details?

The unit includes six shelves (five adjustable, one fixed) with a guard rail on the back.

Description tab
How much does it weigh and what is the shipping weight?

Product weight is 231 lbs. and shipping weight is 256 lbs.

Description tab
What are the electrical requirements?

Rated amperage is 3 Amps, and the facility electrical requirement is 110-120V AC, 15 A minimum. It uses a NEMA 5-15 plug with an 8 to 10 ft typical cord conforming to UL471 requirements.

Description tab
What alarms does the controller provide?

The controller provides visual and audible high/low temperature indicators compliant with alarm requirements defined in the NSF/ANSI 456 Standard for Vaccine Storage, plus state switching remote alarm contacts for external connection.

Temp Controller tab
What warranty is included?

A two (2) year parts and labor warranty, excluding display probe calibration, plus a five (5) year compressor warranty.

Description tab
What does NSF/ANSI 456 certified mean, and who is it for?

NSF/ANSI 456 is the vaccine storage standard from NSF International, which sets performance and construction requirements for vaccine refrigerators and freezers. A certified unit like this one is tested by an independent third-party lab under protocols that go far beyond those for a standard pharmacy refrigerator: vaccine simulation devices are placed at worst-case positions inside the unit and temperatures are recorded 30 to 90 times faster than a typical data logger. It holds temperature within ±0.5°C, with forced-air circulation and dual temperature monitoring with audible and visual alarms. It is for anyone who stores vaccines or other temperature-sensitive pharmaceuticals and needs certified protection through heavy use and frequent door openings: pharmacies, clinics, physician offices, hospitals and immunization programs.

American Biotech Supply
Answers come from this product's record and datasheet. Settings and procedures come from the owner's manual.

Product details for the PH-ABT-NSF-12S

The description, performance figures and controller details, straight from the datasheet.

Need the full datasheet? Use View / Print Product Information above.
Description



Description
Single Solid Door Pharmacy/Vaccine Upright Refrigerator
Operational environment
Indoor use only, +18°C to +26°C (+65°F to +78°F), <70% RH
Storage capacity
12 cu. ft. gross volume
Door
One swing solid door, self-closing, right hinged, non-reversible, magnetic sealed gasket, keyed lock
Shelves
Six shelves (five adjustable/one fixed) with guard rail on back
Mounting
3 1/2″ Swivel Casters(two locking)
Interior lighting
Shielded, switched LED lighting, full coverage, balanced spectrum
Airflow management
Forced Air technology, patent pending
External probe access
Rear wall port (3/4″) dia.
Insulation
Cabinet is foamed-in-place with EPA compliant high density urethane foam
Exterior materials
White powder coated steel
Access control
Pyxis®, Omnicell® and AcuDose RX® compatible
General warranty
Two (2) years parts and labor warranty, excluding display probe calibration
Compressor warranty
Five (5) years compressor warranty
Product Weight
231 lbs.
Shipping Weight
256 lbs.
Rated Amperage
3 Amps
Power Plug/Power Cord
NEMA 5-15 plug, 8 to 10 ft typical, conforms to UL471 requirements, Vaccine Storage power cord warning label
Facility Electrical Requirement
110-120V AC: 15 A (minimum)
Agency Listing and Certification
Certified with the temperature performance requirements as defined in the NSF/ANSI 456 Standard for Vaccine Storage for all testing scenarios. UL, C-UL, ETL, C-ETL listed and certified to UL471 standard, hydrocarbon refrigerant safety.
Included Accessories
Pharmacy refrigerator/freezer toolkit and temperature logs
Uniformity¹ (Cabinet air)
+/- 0.7°C
Stability² (Cabinet air)
+/- 1.3°C
Maximum temperature variation (Cabinet air)
+/-1.1°C
Temperature rise after 8 sec door openings
Temperature did not exceed 5.4°C at any probe for all required NSF/ANSI 456 testing protocolsᶟ
Recovery after 3 min door opening
All probes recover to under 8°C within 2.5 min.
Energy consumption
0.61 KWh/day⁴
Average heat rejection
1.20 KWh/day (315 BTU/h)⁴
Noise pressure level (dBA)
48 or less installed
Pull down time to 4°C nominal operating temp
30 min
Controller technology
Parametric, microprocessor, LED display with 0.1°C resolution
Temperature setpoint range
1°C to 10°C (Setpoint must remain unaltered from the factory setting to remain compliant with NSF/ANSI 456 Standard for Vaccine Storage requirements)
Calibration
Calibrated using a NIST traceable device, certificate included
External alarm connection
State switching remote alarm contacts
Alarms
Visual and audible indicators, High / Low temperature, compliant with alarm requirements defined in the NSF/ANSI 456 Standard for Vaccine Storage
Simulator ballast
Glass bead thermal media
